The refurbished Huawei S5730-44C-PWH-HI is a high-performance Layer 3 Ethernet switch featuring 24 x 10/100/1000 Base-T PoE++ ports and 4 x 10GE SFP+ uplinks. Designed for high-density enterprise access and aggregation layers, it supports advanced routing, MPLS, IPv6, multicast, QoS, and security features. This switch offers hardware-based reliability and is ideal for large-scale networks requiring power delivery and intelligent management.
Key Features & Benefits
24 x Gigabit PoE++ ports and 4 x 10G SFP+ uplinks
Supports Layer 3 routing protocols: OSPF, IS-IS, BGP, RIP
Built-in MPLS L2VPN/L3VPN and IPv6 forwarding capabilities
Supports 256K MAC address entries and 4094 VLANs
PoE++ with max power consumption up to 1,595W
Intelligent fan cooling and heat management
iStack and Ethernet OAM for enhanced reliability
Ideal Uses
Enterprise access layer requiring PoE++ power delivery
Aggregation switch for high-bandwidth voice, video, and data
Large-scale Layer 3 deployments with MPLS and IPv6
High-reliability campus or service provider environments
Specifications
Condition: Refurbished device with minor scratches and scuffs. Device has been extensively tested and is fully functional.
Product Type: Layer 3 Ethernet Switch
Model: Huawei S5730-44C-PWH-HI
Fixed Ports:
24 x 10/100/1000 Base-T PoE++
4 x 10G SFP+
Extended Slots: 2
MAC Address Table: 256K entries
VLANs: 4094
Routing Support: Static, OSPF, IS-IS, BGP, RIP, ECMP
Multicast: IGMP v1/v2/v3, PIM-SM/DM/SSM
IPv6 Support: ND, IPv6 Ping, IPv6 Tracert, IPv6 ACLs
MPLS: L2VPN, L3VPN, MPLS-TE, MPLS QoS
QoS: 8 Queues/Port, DRR, SP, WRED
ACL Support: Layer 2 to Layer 4 filtering
Security Features: 802.1X, Port Security, ARP/ICMP/DoS protection
Reliability: STP, RSTP, MSTP, LACP, Smart Link, RRPP, BFD
Management: SNMP v1/v2c/v3, RMON, System Logs
Power Input:
AC: 100240V, 50/60 Hz
DC: 48V to 60V
Power Consumption:
Max: 1,595W
Without PDs: 105.9W
Cooling: Built-in fans with intelligent speed adjustment
Operating Temperature: 0°C to 45°C
Relative Humidity: 5% to 95% (non-condensing)
Dimensions: 442 mm (W) x 420 mm (D) x 44.4 mm (H)
Warranty: 3 Month Carry-in Warranty
What's in the Box: Huawei S5730-44C-PWH-HI Switch
