ICL8038 Signal Generator Medium/Low Frequency 10Hz-450KHz Triangular/Rectangular/Sine Wave Generator ICL8038 Signal Generator Medium/Low Frequency 10Hz-450KHz Triangular/Rectangular/Sine Wave Generator ICL8038 Signal Generator Medium/Low Frequency 10Hz-450KHz Triangular/Rectangular/Sine Wave Generator ICL8038 Signal Generator Medium/Low Frequency 10Hz-450KHz Triangular/Rectangular/Sine Wave Generator
ICL8038 Signal Generator Medium/Low Frequency 10Hz-450KHz Triangular/Rectangular/Sine Wave Generator ICL8038 Signal Generator Medium/Low Frequency 10Hz-450KHz Triangular/Rectangular/Sine Wave Generator ICL8038 Signal Generator Medium/Low Frequency 10Hz-450KHz Triangular/Rectangular/Sine Wave Generator ICL8038 Signal Generator Medium/Low Frequency 10Hz-450KHz Triangular/Rectangular/Sine Wave Generator

ICL8038 Signal Generator Medium/Low Frequency 10Hz-450KHz Triangular/Rectangular/Sine Wave Generator

20 available / new
R377.00
Shipping
R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate
The seller has indicated that they will usually have this item ready to ship within 12 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery
Main centres:  1-3 business days
Regional areas: 3-4 business days
Remote areas: 3-5 business days
Seller
Buyer protection
Returns
Replacement Guarantee: 7 Days: We stand by this guarantee
Get it now, pay later

Product details

Condition
New
Location
International
Bob Shop ID
641126355
Description:

The LC ICL8038 module is designed for common frequency ranges. It is adjustable from 5 gears and generates low-distortion triangular waves, square and sine waves from 10Hz to 450KHz. Sine wave can be used for test signals, drive signals, carrier frequency signals, etc; square wave can be used for switching signals, trigger signals, etc; triangular wave is mainly used for scanning signals.

Features:

Working voltage: 12V ~ 15V
Output: Triangular wave, Square wave and sine wave.
Frequency range: 10HZ ~ 450kHz
Low distortion sine wave: 1%
Duty cycle range: 2% to 98%
Low temperature drift: 50ppm / a
Triangular wave output linearity: 0.1%
Working temperature: 0 ~ 70 a
Board size: 54.5*37.8mm

Functions:

VCC,GND: working voltage
AC: with DC bias output
G: ground
DC: pure signal output
R11: Frequency adjustment
R12: Square wave duty cycle adjustment
R13: Sine wave linear adjustment
R14: Amplitude adjustment
R15: Square wave linear adjustment
Jumper P2: select different wave-forms(triangular, square or sine waves)
Jumper P3: select different frequency ranges
10Hz-450Hz
90Hz-1.5KHz
940Hz-15KHz
6KHz-120KHz
20KHz-450KHz

Package included:

1 x ICL8038 Low/Medium Frequency Signal Source Waveform Sine Signal Generator Module














, , , , , ,
Add to cart
