Imou Kit 5MP Video Doorbell Outdoor Wi-Fi

DB61i delivers 5MP live monitoring experience with a 5MP sensor. It is able to capture more details with the 164°fish eye lens. DB61i supports night vision mode for clear-as day clarity even in pitch dark. With IP65 certified, the doorbell can be used outdoors under different weather conditions. The support of dual-band Wi-Fi enables DB61i to provide more Wi-Fi choice and extend the Wi-Fi connectivity. Furthermore, it is equipped with a smart night light, which can be used to notify motion detections and illuminate in the night.

Camera Network

• 5 Megapixel progressive CMOS
• 5MP(2560 x 1920)
• Night Vision: 5m(16.5ft) distance
• 2.0mm fixed lens
• Field of View: 164°

Video & Audio

• Video Compression: H.265
• Audio Compression: AAC
• Up to 15fps Frame Rate
• Two-way Bidirectional Talk
• Echo cancellation

Notice Management

• Call Notification
• Motion Detection
• Human Detection
• Configurable Detection Area

Network

• Wi-Fi: IEEE802.11b/g/n,2.4GHz & 5GHz
• Imou life app: iOS, Android

Auxiliary Interface

• Micro SD Slot (up to 256GB)
• Built-in Mic & Speaker
• Reset button
• Micro USB power port

General

• AC16~24V, DC12/24V Power supply
• Power Consumption: <0.7A
• Surface mounted
• Working Environment: -20°C~+50°C, Less than 95%RH
• Dimensions: 110 × 45 × 23mm (4.3 × 1.8 × 0.9inch)
• CE, FCC, FCC ID, IC, IC ID
