Brand New & Sealed with Manufacturer Warranty!
Available: Mon—Fri, 08:00—17:00 - Closed on weekends & public holidays
Impro HCD905 iTRT2 Distributed Controller in Plastic Enclosure HCD905-0-0-GB-00
Features:
Technical Specifications:
Product Description: iTRT2 Plastic Enclosure (No PSU)
Colour: Grey module & Black/White Enclosure
Dimensions (D × W × H): 100â¯mm × 230â¯mm × 260â¯mm
Approx. Product Weight: 1.15â¯kg
Material: PC Plastic Module in ABS Plastic Enclosure
Electrical Specifications
Input Voltage: 12â¯V
Power Requirements at 12â¯V DC: 120â¯mA
Relay Power Requirements: 0.45â¯W per relay
Power Input Protection: N/A
Interconnectivity
Ethernet: 10/100 Base-T
RS-485 Ports: 1 × 38400 RS-485 for controller networking, 1 × 38400 RS-485 for Aperio™ lock hubs
OSDP & Wiegand: 2 hardware-selectable ports for OSDP or legacy Wiegand
Status LEDs: 20
Input Specification
Digital Inputs: 2 × Door Open Sensor inputs, 2 × Request to Exit Button inputs
Input Type: 4 dry contact inputs with end-of-line (EOL) sensing
Output Specification
Number of Relay Outputs: 3
Output Type: 3 × independent SPDT dry contact relays (NO, COM, NC)
Relay Contacts: Normally Open, Common, Normally Closed
Contact Ratings: 5â¯A - 28â¯V DC (TV-5 Rated), 100k operations minimum
Environmental Specifications
Operating Temperature: -25⯰C to +60⯰C (-13⯰F to +140⯰F)
Storage Temperature: -40⯰C to +85⯰C (-40⯰F to +176⯰F)
Operating Humidity: 0—95% RH non-condensing (at +40⯰C / +104⯰F)
Environmental Rating: IP40
Certifications
CE (EU): Yes
UL: On request
SABS (RSA): Yes
RoHS Compliance: Yes
