| MODEL | Mecer/InfiniSolar Plus 3KW |
| PHASE | 1-phase in / 1-phase out |
| RATED OUTPUT POWER | 3000 W |
| GRID-TIE OPERATION | |
| PV INPUT (DC) | |
| Maximum PV Input Power | 4500W |
| Nominal DC Voltage / Maximum DC Voltage | 360 VDC / 500 VDC |
| Start-up Voltage / Initial Feeding Voltage | 116 VDC / 150 VDC |
| MPP Voltage Range | 250 VDC ~ 450 VDC |
| Number of MPP Trackers / Maximum Input Current | 1 / 1 x 18 A |
| GRID OUTPUT (AC) | |
| Nominal Output Voltage | 208/220/230/240 VAC |
| Output Voltage Range | 184 - 264.5 VAC* |
| Nominal Output Current | 13 A |
| Power Factor | > 0.99 |
| EFFICIENCY | |
| Maximum Conversion Efficiency (DC/AC) | 96% |
| European Efficiency@ Vnominal | 95% |
| OFF-GRID OPERATION | |
| AC INPUT | |
| AC Start-up Voltage/Auto Restart Voltage | 120 - 140 VAC / 180 |
| Acceptable Input Voltage Range | 170 - 280 VAC |
| Maximum AC Input Current | 30 A |
| PV INPUT (DC) | |
| Maximum DC Voltage | 500 VDC |
| MPP Voltage Range | 250 VDC ~ 450 VDC |
| Number of MPP Trackers / Maximum Input Current | 1 / 1 x 18 A |
| BATTERY MODE OUTPUT (AC) | |
| Nominal Output Voltage | 202/208/220/230/240 VAC |
| Output Waveform | Pure Sinewave |
| Efficiency (DC to AC) | 93% |
| HYBRID OPERATION | |
| PV INPUT (DC) | |
| Nominal DC Voltage / Maximum DC Voltage | 360 VDC / 500 VDC |
| Start-up Voltage / Initial Feeding Voltage | 116 VDC / 150 VDC |
| MPP Voltage Range | 250 VDC ~ 450 VDC |
| Number of MPP Trackers / Maximum Input Current | 1 / 1 x 18 A |
| GRID OUTPUT (AC) | |
| Nominal Output Voltage | 202/208/220/230/240 VAC |
| Output Voltage Range | 184 - 264.5 VAC* |
| Nominal Output Current | 13 A |
| AC INPUT | |
| AC Start-up Voltage / Auto Restart Voltage | 120 - 140 VAC / 180 VAC |
| Acceptable Input Voltage Range | 170 - 280 VAC |
| Maximum AC Input Current | 30 A |
| BATTERY MODE OUTPUT (AC) | |
| Nominal Output Voltage | 202/208/220/230/240 VAC |
| Efficiency (DC to AC) | 93% |
| BATTERY & CHARGER | |
| Nominal DC Voltage | 48 VDC |
| Maximum Charging Current | 25A |
| GENERAL | |
| PHYSICAL | |
| Dimension, D X W X H (mm) | 107 x 438 x 480 |
| Net Weight (kgs) | 15.5 |
| INTERFACE | |
| Communication Port | RS-232/USB |
| Intelligent Slot | Optional SNMP, Modbus, and AS-400 cards available |
| ENVIRONMENT | |
| Humidity | 0 ~ 90% RH (No condensing) |
| Operating Temperature | 0 to 40°C |
| Altitude | 0 ~ 1000 m** |
| Product specifications are subject to change without further notice. | |
