| SPECIFICATIONS |
| Brand | Intel |
| Series | 14th Gen Raptor Lake-S |
| Model | BX8071514400 |
| Essentials |
| Vertical Segment | Desktop |
| Lithography | Intel 7 |
| Core Arrangement | 6 Performance Cores, 4 Efficiency Cores |
| Cores | 10 |
| Threads | 16 |
| Performance-core Max Turbo Frequency | 4.70GHz |
| Efficient-core Max Turbo Frequency | 3.50GHz |
| Performance-core Base Frequency | 2.50GHz |
| Efficient-core Base Frequency | 1.80GHz |
| Cache | 20 MB Intel Smart Cache |
| Total L2 Cache | 9.5MB |
| Processor Base Power | 65W |
| Maximum Turbo Power | 148W |
| TJUNCTION | 100°C |
| Memory |
| Max Memory Supported | 192 GB |
| Memory Types | Up to DDR5 4800MT/s |
| Up to DDR4 3200MT/s |
| Max Number of Memory Channels | 2 |
| Max Memory Bandwidth | 76.8GB/s |
| Graphics |
| Processor Graphics | Intel UHD Graphics 730 |
| Graphics Base Frequency | 300 MHz |
| Graphics Max Dynamic Frequency | 1.55GHz |
| Graphics Output | eDP 1.4b, DisplayPort 1.4a, HDMI 2.1 |
| Execution Units | 24 |
| Max Resolution (HDMI) | 4096 x 2160 @ 60Hz |
| Max Resolution (DP) | 7680 x 4320 @ 60Hz |
| API Support | DirectX 12.1, OpenGL 4.5, OpenCL 3.0, Vulkan |
| Multi-Format Codec Engines | 1 |
| Intel Quick Sync Video Support | Yes |
| Intel Clear Video HD Technology Support | Yes |
| Number of Displays Supported | 4 |
| Expansion |
| Direct Media Interface (DMI) Revision | 4 |
| Max Number of DMI Lanes | 8 |
| Scalability | Single socket |
| PCI Express Revision | 5.0 and 4.0 |
| PCI Express Configurations | Up to 1x16 plus 4 lanes OR 2x8 plus 4 lanes |
| Max Number of PCI Express Lanes | 20 |
| General |
| Advanced Features | Intel Gaussian & Neural Accelerator 3.0 |
| Intel Thread Director |
| Intel Deep Learning Boost (Intel DL Boost) |
| Intel Speed Shift Technology |
| Intel Turbo Boost Technology 2.0 |
| Intel Hyper-Threading Technology |
| Intel 64 |
| 64-bit Instruction Set |
| Intel SSE4.1, Intel SSE4.2, Intel AVX2 Instruction Set Extensions |
| Idle States |
| Enhanced Intel SpeedStep Technology |
| Thermal Monitoring Technologies |
| Intel Volume Management Device (VMD) |
| Security & Reliability Features | Intel Standard Manageability (ISM) |
| Intel Control-Flow Enforcement Technology |
| Intel AES New Instructions |
| Secure Key |
| Intel OS Guard |
| Intel Trusted Execution Technology |
| Execute Disable Bit |
| Intel Boot Guard |
| Mode-based Execute Control (MBEC) |
| Intel Stable IT Platform Program (SIPP) |
| Intel Virtualization Technology with Redirect Protection (VT-rp) |
| Intel Virtualization Technology (VT-x) |
| Intel Virtualization Technology for Directed I/O (VT-d) |
| Intel VT-x with Extended Page Tables (EPT) |
| Operating System Support | Windows 10 64-bit |
| Windows 11 64-bit |
| Linux x86-64 |
| Warranty Information |
| Warranty | 3 Year Warranty |
