NOTE: Sandy Bridge technology only supports 2nd Generation Socket 1155
Microarchitecture
Sandy Bridge | |
Processor core | Sandy Bridge |
Core stepping | Q0 (QA25, SR05C) |
Manufacturing process | 0.032 micron High-K metal gate process |
Data width | 64 bit |
The number of CPU cores | 2 |
The number of threads | 4 |
Floating Point Unit | Integrated |
Level 1 cache size | 2 x 32 KB 8-way set associative instruction caches 2 x 32 KB 8-way set associative data caches |
Level 2 cache size | 2 x 256 KB 8-way set associative caches |
Level 3 cache size | 3 MB 12-way set associative shared cache |
Cache latency | 4 (L1 cache) 12 (L2 cache) 27 (L3 cache) |
Physical memory | 32 GB |
Multiprocessing | Uniprocessor |
Extensions and Technologies |
|
Security Features |
|
Low power features |
|
Integrated peripherals / components | |
Integrated graphics | GPU Type: HD 2000 Microarchitecture: Gen 6 Execution units: 6 Base frequency (MHz): 850 Maximum frequency (MHz): 1100 The number of supported displays: 2 |
Memory controller | The number of controllers: 1 Memory channels: 2 Supported memory: DDR3-1066, DDR3-1333 Maximum memory bandwidth (GB/s): 21.3 |
Other peripherals |
|
Electrical / Thermal parameters | |
Maximum operating temperature | 69.1°C |
Thermal Design Power | 65 Watt |
