Intel NUC Kit with 5th Generation Intel Core Processor - Intel Core i3 Broadwell Dual Core i3-5005U 2.00Ghz 3MB L3 Cache Processor, Hyper-Threading Technology, Enhanced Intel SpeedStep Technology, Intel Virtualization Technology, Intel Wireless Display, Intel 64 Technology, 0 MB installed, 16GB max - DDR3L SDRAM, SATA 6Gb/s Storage Controller, No Hard Drive, No Optical Drive, Intel HD Graphics 5500, 7.1 Channel Surround Sound Card, Gigabit Ethernet Controller, WIFI 802.11b/g/n/ac, No Operating System, Retail Box, 1 Year Warranty
Specifications
• Product Code: BOXNUC5I3RYHS
• Description: Intel NUC Kit with 5th Generation Intel Core Processor
Essentials
• Board Form Factor: UCFF (4" x 4")
• Socket: Soldered-down BGA
• Internal Drive Form Factor: M.2 and 2.5" Drive
• # of Internal Drives Supported: 2
• Lithography: 14 nm
• TDP: 15 W
• DC Input Voltage Supported: 12-19 VDC
• Processor Included: Intel® Core™ i3-5005U Processor (3M Cache, 2.00 GHz)
Memory & Storage
• Max Memory Size (dependent on memory type): 16 GB
• Memory Types: DDR3L-1333/1600 1.35V SO-DIMM
• Max # of Memory Channels: 2
• Max Memory Bandwidth: 25.6 GB/s
• Max # of DIMMs: 2
Processor Graphics
• Processor Graphics ‡: Intel® HD Graphics 5500
• Integrated Graphics ‡: Yes
• Graphics Output: Mini-DP 1.2; Mini-HDMI 1.4a
• Intel® Clear Video Technology: Yes
• # of Displays Supported ‡: 3
Expansion Options
• PCI Express Revision: Gen2
• PCI Express Configurations ‡: M.2 slot with PCIe X4 lanes
• M.2 Card Slot (storage): 22x42/60/80
I/O Specifications
• # of USB Ports: 6
• USB Configuration: 2x front and 2x rear USB 3.0; 2x USB 2.0 via internal headers
• USB Revision: 2.0, 3.0
• USB 2.0 Configuration (External + Internal): 0 + 2
• USB 3.0 Configuration (External + Internal): 2B 2F +0
• Total # of SATA Ports: 1
• Max # of SATA 6.0 Gb/s Ports: 1
• Audio (back channel + front channel): 7.1 digital (mHDMI mDP); L+R+mic (F)
• Integrated LAN: Intel® Ethernet Connection I218-V
• Integrated Wireless: Intel® Dual Band Wireless-AC 7265
• Integrated Bluetooth: Yes
• Consumer Infrared Rx Sensor: Yes
• Additional Headers: 2x USB2.0, AUX_PWR
