CPU Specifications
Total Cores 2
Total Threads 4
Processor Base Frequency 3.50 GHz
Cache 3 MB
Bus Speed 8 GT/s
# of QPI Links 0
TDP 54 W
Supplemental Information
Marketing StatusDiscontinued
Launch Date Q1'17
Servicing Status ESU Notification Issued
End of Servicing Updates Date Sunday, March 31, 2024
Embedded Options Available No
DatasheetView now
Memory Specifications
Max Memory Size (dependent on memory type) 64 GB
Memory Types DDR4-2133/2400, DDR3L-1333/1600 @ 1.35V
Max # of Memory Channels 2
ECC Memory Supported Yes
GPU Specifications
GPU Name Intel® HD Graphics 610
Graphics Base Frequency 350 MHz
Graphics Max Dynamic Frequency 1.05 GHz
Graphics Video Max Memory 64 GB
4K Support Yes, at 60Hz
Max Resolution (HDMI) 4096x2304@24Hz
Max Resolution (DP) 4096x2304@60Hz
Max Resolution (eDP - Integrated Flat Panel) 4096x2304@60Hz
DirectX* Support 12
OpenGL* Support 4.4
Intel® Quick Sync Video Yes
Intel® InTru 3D Technology Yes
Intel® Clear Video HD Technology Yes
Intel® Clear Video Technology Yes
# of Displays Supported 3
Device ID0x5902
Expansion Options
Scalability1S Only
PCI Express Revision 3.0
PCI Express Configurations Up to 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes 16
Package Specifications
Sockets Supported FCLGA1151
