Features
Simulated sinewave inverter
Wide input voltage range
12VDC or 24VDC available
Overload and short circuit protection
LCD display for comprehensive information
Optional solar charger
MODELIVR-2400LBKS
CAPACITY 2400VA/ 1440W
INPUT
Voltage230 VAC
Acceptable Voltage Range90-280 VAC
Frequency50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode) 10%
Efficiency (Peak)82%85%
Transfer Time20 ms typical
Waveform (Batt. Mode)Simulated sine wave
BATTERY & AC CHARGER
Battery Voltage12 VDC24 VDC
Floating Charge Voltage13.7 VDC 2%27.4 VDC 2%
Low Battery Alarm Voltage10.2Vdc 2%20.4Vdc 2%
Shutdown Voltage9.9Vdc 2%19.8Vdc 2%
Overcharge Protection15.0Vdc 2%30.0Vdc 2%
Maximum Charge Current10 A or 20 A (Selectable)
SOLAR CHARGER (Optional) Solar Charge controller not included,will request to purchase separately
Maximum PV Array Open Circuit Voltage40 VDC60 VDC
Operating Voltage Range15~18 VDC30~32 VDC
Maxmum Solar Charge Current50 A
PROTECTION
Full ProtectionOverload, short circuit and polarity reserve protection
PHYSICAL
Dimension, D X W X H (mm)300 x 360 x 88
Net Weight (kgs)4.64.8
OPERATING ENVIRONMENT
Humidity0 to 90% Relative Humidity(Non-condensing)
Operating Temperature0? to 40?
Storage Temperature-15? to 50?
