Specification:
Power Supply Voltage: Dual DC power supply of 58-70V.
Rated Output Power: 500W (at 65V supply with 4-ohm load, distortion <10%).
Efficiency: >= 90%.
Signal-to-Noise Ratio: 90dB.
Total Harmonic Distortion:
380W (with +65V supply and 4-ohm speaker, distortion <0.1%).
280W (with +65V supply and 8-ohm speaker, distortion <0.1%).
Frequency Response Range: 20Hz - 20KHz.
Speaker Compatibility: Suitable for 4-ohm to 8-ohm speakers.
Voltage Amplification Factor: 36 times.
Input Sensitivity: 1.5V (RMS).
Output Short Circuit Protection: Available.
Output DC Offsett Protection (Speaker Protection): Available.
Overtemperature Protection: If the heat sink FET temperature exceeds 100°C, the output will be automatically shut down.
Size:98mm*43mm*30mm
