Resolution 203dpi, 300dpi Printing method Direct Thermal and Transfer Thermal Max. print speed 6ips @ 203dpi, 4ips @ 300dpi Max. print width 4.25"(108mm) @ 203dpi and 4.17"(106mm) @ 300dpi Max. print length 90"(2,286mm) @ 203dpi, 60"(1,524mm) @ 300dpi Physical dimension(W x H x D) 7.09"(180mm) × 11.54"(293mm) × 9.33"(237mm) Weight 6.17lbs(2.8kg) Processor 32-bit RISC CPU Memory 16 MB Flash / 16 MB RAM Interface Standard: USB-B and Ethernet 10/100Base T Optional: Bluetooth 5.2/LE(factory option) WiFi security encryption N/A WiFi security authentication N/A Power External universal switching power supply Input: AC 100~240V, 2.5A, 50~60 Hz Output: DC 24V 2A, 48W User interface 2 operation buttons(power,feed) 2 LEDs with 3 colors Sensors Gap transmissive sensor Black mark reflective sensor (position adjustable) Head open sensor Ribbon end sensor Internal fonts 8 resident expandable ZPL II bitmap fonts Simplified Chinese, Traditional Chinese Downloadable objects include graphics, scalable and bitmap fonts, label templates and formats IBM Code Page 850 international character sets are available in the fonts A, B, C, D, E, F, G and 0 through software control Code Page 1250, 1251, 1252, 1253, 1254, 1255, 1256 Support with font 0 Graphic formats PCX,BMP Bar code 1D barcode: UPC-A, UPC-E, Codabar, CODE128, CODE39, CODE93, EAN-8, EAN-13, UCC/EAN128, POSTNET, ITF14, MSI, Plessey, Telepen, GS1 DataBar, German Post Code, Interleaved 2 of 5, Standard 2 of 5, Industrial 2 of 5, CODE11, EAN14 2D barcode: PDF417, Data Matrix, Maxicode, QR Code, MicroPDF471, Aztec Font and barcode rotation 0, 90, 180, 270 degree Printer Language ZPL-II, TSPL, DPL, EPL2 Media type Continuous, die-cut, black mark, fan-fold, notch Media handling Standard: Continuous, Tear-Off / Options: Peel-Off, Cut Media width Min 1"(25.4mm) / Max 4.65"(118mm) Media thickness 0.002"(0.06mm) to 0.010"(0.250mm) Media core diameter 0.5"(12.7mm)/ 1"(25.4mm)/ 1.5"(38.1mm) Media max. roll diameter 5.0"(127mm) Media length Min.: Tear-Off 0.24"(10mm) @ 203dpi, 0.2"(8mm) @ 300dpi Min.: Peel-Off , Cutter 1.0"(25.4mm) Max.: 90"(2,286mm) @ 203dpi, 60"(1,524mm) @ 300dpi Ribbon type Wax, Wax/Resin, Resi Ribbon length 984.3 ft(300m) Ribbon core diameter 1.0"(25.4mm) Ribbon width Min 1.18"(30mm) / Max 4.33"(110mm) Environment condition Operating Temperature: 41° to 122°F (5° to 50°C) (limitations based on selected media) / Operating Humidity: 25 to 85% RH Non-Condensing Storage Temperature: -4° to 140° F (-20° to 60° C) / Storage Humidity: Non-Condensing Safety Certification CCC, FCC, CE, CB, Energy Star Environmental concer RoHS, WEEE Options Bluetooth 5.2/LE(factory option) Peel Guillotine Cut
