ITW Switches (19N402R15) Microswitch, Snap Action, Roller Lever, SPDT

Microswitch, Snap Action, Roller Lever, SPDT, Solder, 5 A, 28 VDCProduct InformationMicroswitch Type: Snap ActionMicroswitch Actuator: Roller LeverContact Configuration: SPDTSwitch Terminals: SolderContact Current Max: 5AContact Voltage DC Nom: 28VDCProduct Range: 19NContact Voltage AC Nom: 250VACOperating Force Max: 2NProduct OverviewThe 19N series switches from ITW are miniature microswitches. These switches arehigh quality products suited for large volume applications. The spring and blademethod is used as a switching mechanism and available in different operatingforces. All versions have a fully sealed base right up to the bottom opening. Inaddition, sealed button versions are totally environmental sealed.Fully sealed to IP67Wide temperature range from -40°C to +125°CStandard roller leverNon flammable switch to UL94-V0 ratedSilver contactsBEAB approvedPCB TerminalsOperating force of 0.5NOperating force of 0.5N, 2N, 1.5NApplicationsIndustrial, Power Management, Automation & Process Control
