J5create JUPW1102W Mightywave 10W 2-Coil Wireless Charger

Features:

Hardware

10W Wireless Charger

Coil

2
Input

5V/2A, 9V/2A, 12V/1.5A
Output

5V/1A or 1.5A, 9V/1.1A
Quick Charge 3.0 Charger

Input

100-240V to 50/60 Hz, 0.5A
Output

5V/3A, 9V/2A, 12V/1.5A
Indicator Light

When connected to a power outlet - Flashes blue, white 3 times and then white stays lit

When charging - Fading warm white, blue 3 times and then turns off

When not charging properly due to foreign object detection - Flashes blue, then enters protection mode and stops charging until the foreign object is removed

When not charging properly due to overheating - Flashes blue and white, then enters protection mode and stops charging until the temperature reaches a safe level

Physical Specifications

Dimensions

10W Wireless Charger:
3.43 (W) x 2.69 (H) x 4 (D) in. /
87 (W) x 68.4 (H) x 117.8 (D) mm
Quick Charge 3.0 Charger:
1.77 (W) x 2.18 (H) x 0.92 (D) in. /
45 (W) x 55.4 (H) x 23.4 (D) mm
USB-C cable:
3.3 ft / 100 cm
Weight

10W Wireless Charger:
Approximately 0.23 lb / 105.5 g
Quick Charge 3.0 Charger:
Approximately 0.13 lb / 58.5 g
Environmental

Storage Temperature

-20 70°C
Storage Humidity

5 95% RH. Non-condensing
Operation Temperature

0 25°C
Operation Humidity
