JDY-16 bluetooth 4.2 Module Low Power High Speed Data Transfer Mode BLE Module Compatible With CC254

20 available / new

R399.00

Shipping

R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate

The seller has indicated that they will usually have this item ready to ship within 12 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery

Main centres:	1-3 business days
Regional areas:	3-4 business days
Remote areas:	3-5 business days

Seller

szulou3465

93.39 % Positive ratings

Buyer protection

How you're covered

Returns

Replacement Guarantee: 7 Days: We stand by this guarantee

Get it now, pay later

Condition

New

Location

International

Bob Shop ID

641126727

Description: JDY-16 Version supports(WeChat, APP, Android) Transparent, IO, RTC, PWM and other functions 1.BLE high speed transparent transmission supports 8K Bytes rate communication 2.Send and receive data without byte limit, support 115200 baud rate often send and receive data 3.Support 3 modes of work 4.Support(serial port, IO, APP) sleep wake up 5.Support Wechat Airsync, Wechat applet and APP communication 6.Support 4 channel IO port control 7.Support high precision RTC clock 8.Support PWM function(can be controlled by UART, IIC, APP, etc.) 9.Support UART and IIC communication mode, default to UART communication Technical Parameters: 1. Serial port transmission and reception without byte limit during transparent transmission 2. Effective communication distance within 80 meters 3. Working temperature: -40~+80ﾣC 4. Communication rate 8k Bytes per second 5. Support UART and IIC communication mode 6. Working voltage: 1.8-3.3V Factory default default parameter configuration: 1. Communication method: UART (SELECT pin is left floating) 2. Serial port baud rate: 9600 (AT+BAUD4) 3. Sleep mode: power on sleep, connection wake up (AT+STARTEN1) 4. Broadcast name: JDY-16 (AT+NAMEJDY-16) 5. Broadcast interval: 200MS (AT+ADVIN2) 6. Master-slave mode: Pass-through transmission (AT+HOSTEN0) 7. Output status: Connected or disconnected status is output from the serial port (AT+ENLOG1) 8. Broadcast LED indicator pin on (AT+ALED1)

Package included:

1 xJDY-16 bluetooth 4.2 Module
