15-Preset Eq Including "Drvn Eq"
Preset Eq Patterns Are Selectable From 15 Types Including "Drvn Eq" That Is Designed To Maximize The Performance Of Jvc Drvn Series Amplifiers And Speakers, As Well As Producing Dynamic Sound For Any Speaker.
Media Playback
Flac Compatible With Tag
Compatible With Flac Format Which Allows Digital Audio To Be Losslessly Compressed, So That File Size Is Reduced Without Any Information Being Sacrificed. Also Compatible With Playback Of 16bit / 48khz Flac Format.
Smartphone Integration
Android Music Playback Via Usb (Auto Mode/Audio Mode)
Simply Connect Your Android Smartphone Or Tablet To The Receiver Via Usb And Enjoy A Totally "Plug And Play" Music Playback Solution. The Android Open Accessory Protocol (Aoa2) Is Supported So Absolutely No Preparation Or Set-Up Is Necessary Just Plug It In And It's Ready To Play Audio Files Stored On Your Android Device In What's Called "Audio Mode". Or, By Installing The Free Jvc Music Play App* Available On Google Play, You'll Be Able To Access "Auto Mode" For Added Functionality Including Folder Up & Down, And Search Artist/Album/Song.
Short Body
The Reduced Depth Of The Chassis Contributes To A Weight Reduction And Facilitates Easier Installation.
Technical Specifications
Display
Display Type
Va Lcd Display
Lcd Color
White
Key Color
Red
Spanish Text Display Compatible
Yes
Auto Dimmer
Yes
Brightness Control
Yes
Media Playback
Mp3 Compatible With Tag
Usb
Wma Compatible With Tag
Usb
Wav Compatible With Tag
Usb
Flac Compatible With Tag
Usb ( Up To 48khz/16bit )
Android Control
Android Music Playback
Yes (Audio Mode & Auto Mode)
*Android (Ver 4.1 And Above) / Auto Mode Requires Jvc Music Play Application.
Ipod/Iphone Control
Ipod/Iphone Music Playback
Yes (Via Usb)
Usb
Position
Front
Usb Power Supply
Yes, (1a)
Drive Change Mode For Mass Storage Class
Yes
Inputs And Outputs
Aux Input
1 (Front)
Line Output Terminals (Pair)
2 Pairs (Front + Rear/Subwoofer Selectable)
Pre-Output Level
2.5v
Subwoofer Output With Level/Frequency Control
Yes (Level -8 +8)
Subwoofer Output Level
2.5v
Tuner
Radio Data System (Rds)
Yes
Preset Stations
18fm + 6am + 12sw
Strong Station Memory (For Fm)
Yes
Radio Timer
Yes, (Once/Daily/Weekly)
Tuner Preset Memory (For Power Disconnection)
Yes
Fm Frequency Range
87.5 108.0mhz
Am Frequency Range
(Mw) 531 1,602khz (9khz), (Sw1) 2,940 Khz To 7,735 Khz (5 Khz Step), (Sw2) 9,500 Khz To 10,135 Khz (5 Khz Step) / 11,580 Khz To 18,135 Khz (5 Khz Step)
Audio
Maximum Power Output
50w X 4 / 50w X 2 +Subwoofer (4 Ohms) 50w X 1
Full Bandwidth Power (At Less Than 1%Thd)
22w X 4
Sub Woofer Direct Connection (Mono Lch)
Yes
Eq
Yes (3-Band Parametric Eq)
Preset Eq
Yes (15-Preset)
Loudness Control
Yes, (Off/Low/High)
Bass Boost
Yes
High-Pass Filter/Low-Pass Filter
/Yes
General
Detachable Face Panel
Yes
Carrying Case
Yes
Wireless Remote Control
Yes
Steering Remote Control Ready
Yes
Installation Size (W X H X D)
182 X 53 X 100mm
Weight
0.6kg
Shallow Chassis
Yes
Unit Weight In Individual Package
0.8kg
