15-Preset EQ including "drvn EQ"
Preset EQ patterns are selectable from 15 types including "drvn EQ" that is designed to maximize the performance of JVC drvn Series amplifiers and speakers, as well as producing dynamic sound for any speaker.
Android™ Music Playback via USB
(AUTO MODE/AUDIO MODE)
Simply connect your Android smartphone or tablet to the receiver via USB and enjoy a totally "plug and play" music playback solution. The Android Open Accessory Protocol (AOA2) is supported so absolutely no preparation or set-up is necessary — just plug it in and it's ready to play audio files stored on your Android device in what's called "AUDIO MODE". Or, by installing the free JVC Music Play app* available on Google Play, you'll be able to access "AUTO MODE" for added functionality including Folder Up & Down, and Search Artist/Album/Song.
Display
Display Type
VA LCD Display
LCD Color
White
Key Color
Red
Russian Text Display Compatible
Yes
Spanish Text Display Compatible
Yes
Auto Dimmer
Yes
Brightness Control
Yes
Media Playback
MP3 Compatible with Tag
CD / USB
WMA Compatible with Tag
CD / USB
WAV Compatible with Tag
USB
FLAC Compatible with Tag
USB ( Up to 48kHz/16bit )
Android Control
Android Music Playback
Yes (AUDIO MODE & AUTO MODE)[1]
USB
Position
Front
USB Power Supply
Yes (1A)
Drive Change Mode for Mass Storage Class
Yes
Inputs and Outputs
AUX Input
1 (Front)
Line Output Terminals (Pair)
2 Pairs (Front + Rear/Subwoofer Selectable)
Pre-Output Level
2.5V
Subwoofer Output with Level/Frequency Control
Yes (Level -8 — +8)
Subwoofer Output Level
2.5V
Tuner
Radio Data System (RDS)
Yes
Tuner Type
Digital Processing Tuner
Yes
Preset Stations
18FM + 6AM
Strong Station Memory (for FM)
Yes
Radio Timer
Yes (Once/Daily/Weekly)
Tuner Preset Memory (for power disconnection)
Yes
FM
Frequency Range
87.5 — 108.0MHz
AM
Frequency Range
(MW) 531 — 1,602kHz (9kHz), (LW) 153 — 279kHz (9kHz)
Audio
Maximum Power Output
50W x 4 / 50W x 2 +Subwoofer (4 ohms) 50W x 1
Full Bandwidth Power (at less than 1%THD)
22W x 4
MOS-FET Amplifier
Yes
Subwoofer Direct Connection (Mono Lch)
Yes
EQ
Yes (3-Band Parametric EQ)
Preset EQ
Yes (15-Preset)
Digital Track Expander
Yes
Bass Boost
Yes
Loudness Control
Yes (Off/Low/High)
High-Pass Filter/Low-Pass Filter
— /Yes
drvn EQ
Yes
General
Detachable Face Panel
Yes
Carrying Case
Yes
Steering Remote Control Ready
Yes
