Sound Optimization
15-Preset EQ: Includes "drvn EQ," designed for JVC drvn Series amplifiers and speakers to maximize performance and provide dynamic sound.
Bass Boost: Adjustable to enhance low frequencies.
Loudness Control: Options include Off, Low, and High settings.
3-Band Parametric EQ: Allows fine-tuned adjustments to audio frequencies.
High-Pass Filter: Not available.
Low-Pass Filter: Available for better sound control.
Subwoofer Direct Connection (Mono Left Channel): Supported.
Subwoofer Output: With adjustable level and frequency control (-8 to +8).
Media Playback
FLAC Compatible: Supports up to 16-bit/48kHz FLAC files for lossless audio playback.
MP3/WMA/WAV Compatible: All supported via USB.
File Tag Support: Compatible with metadata tags for track info (artist, title, album). General Features Short Chassis: Compact design with reduced depth for easier installation.
Detachable Face Panel: Provides added security when removed.
Carrying Case: Included for storing the detachable face panel.
Steering Remote Control Ready: Works with third-party adapters (sold separately).
Weight: 0.6 kg (unit only); 0.8 kg (with packaging).
Installation Dimensions: 182 x 53 x 100 mm.
Display
Display Type: VA LCD with a white color scheme.
Key Illumination: Red.
Language Support: Russian and Spanish text display compatible.
Auto Dimmer: Adjusts brightness automatically.
Brightness Control: Manual adjustment available.
USB
Position: Front-mounted USB port.
Power Supply: Up to 1A for charging connected devices.
Drive Change Mode: Allows control of storage devices in mass storage class mode.
Inputs and Outputs
AUX Input: Front-mounted (1 input).
Line Output Terminals: Two pairs (Front + Rear/Subwoofer selectable).
Pre-Output Level: 2.5V.
Subwoofer Output: Supported with 2.5V level and adjustable frequency/level control.
Tuner
Radio Data System (RDS): Displays station and track info when available.
Preset Stations: 18 FM and 6 AM.
Strong Station Memory: Saves strongest FM stations automatically.
Radio Timer: Configurable for Once, Daily, or Weekly schedules.
FM Frequency Range: 87.5-108.0 MHz.
AM Frequency Range: MW: 531-1,602 kHz (9 kHz); LW: 153-279 kHz (9 kHz).
Audio
Maximum Power Output:
50W x 4 channels.
50W x 2 channels + Subwoofer (4 ohms) 50W x 1 channel.
Full Bandwidth Power: 22W x 4 channels (<1% THD).
Preset EQ Patterns: 15, including "drvn EQ."
