KCD5-105 Round Rocker Switch 250V 3A SPST ON OFF Red
The KCD5-2-105 on-off sub-miniature rocker switch offers a low switching current in a compact design. It is a snap-in mounted rocker switch with a high mechanical life in a rugged nylon 66 housing. They have high quality for long life at heavy loads and industry-standard mounting dimensions. This rocker switch can be used in a variety of applications, like water dispenser and extension socket and so on.
Product description
Product Name:Rocker Switch
Connection Type:SPST
Position:On-Off
Terminals Number: 2
Rating Voltage/Current
AC 250V 3A
AC 125V 6A
Total Size(Each):16mm
Mounted Size: 15mm
Contact Resistance: 50mΩ max
Insulation Resistance: 100mΩ min (500VDC)
This item is available in stock and is not drop shipped. This avoids delays, customs charges and extra VAT.
