Kemet (050MS22AAMA1STD) Electrolytic Capacitor, Motor Start, 50 µF

Electrolytic Capacitor, Motor Start, 50 µF, 220 VAC, 0%, +25%, Quick Connect,Snap-InProduct InformationCapacitance: 50µFVoltage Rating: 220VACVoltage(AC): 220VACCapacitance Tolerance: 0%, +25%Capacitor Terminals: Quick Connect, Snap-InLifetime @ Temperature: 500 hours @ 60°CSeries Name: Motor StartPolarity: Bi-Polar [Non-Polar]Diameter: 39mmLead Spacing: -Product Diameter: 39mmOperating Temperature Min: -20°COperating Temperature Max: 60°CHeight: 75mmESR: -Product Height: 75mmProduct Length: -Product Width: -Qualification: -Product Range: Motor StartAutomotive Qualification Standard: -Product OverviewThe MS series Aluminium Electrolytic Capacitor designed for intermittent dutyonly and capable of withstanding the AC voltage applied to the motor duringstarting. The capacitor construction is comprised of either double anode orO-style (double anode and floating cathode) windings, which are housed in amoulded plastic case. This MS series capacitor specifically designed for ACoperation which helps to start the motor by providing a leading current to theauxiliary winding. The capacitor is not permanently connected to the winding ofthe motor and is usually switched off automatically after starting.6.3mm double amp tags (quick connect types)VDE approved to IEC 60252-2
