Kemet (ALA7DA301CC450) Electrolytic Capacitor, 300 µF, 450 V

Electrolytic Capacitor, 300 µF, 450 V, ± 20%, Quick Connect, Snap-In, 13000hours @ 85°CProduct InformationCapacitance: 300µFVoltage Rating: 450VVoltage(DC): 450VVoltage(AC): -Capacitance Tolerance: ± 20%Capacitor Terminals: Quick Connect, Snap-InLifetime @ Temperature: 13000 hours @ 85°CPolarity: PolarDiameter: 30mmProduct Range: ALA7DProduct Diameter: 30mmProduct Height: 35mmLead Spacing: 10mmESR: 0.5042ohmOperating Temperature Min: -40°COperating Temperature Max: 85°CProduct Length: -Product Width: -Qualification: AEC-Q200Product OverviewThe KEMET ALA Snap-In Capacitors are designed for automotive applications. Theycan withstand vibration up to 20 G in accordance with the demanding requirementsof the Automotive Electronics Council's AEC-Q200 qualification. The ALA7Dcapacitance values cover a range from 240 to 820 µF and voltage ranges of 400 to500 V.Designed for automotive usagesVibration proofAEC-Q200Long life, up to 15,000 hours at +85°C (Vr Ir applied)High ripple currentExcellent surge voltage capabilityPET sleeve recognized to UL QMTR2, UL No. E358957Optimized designs available upon request
