Kemet (ALA8DA391DC400) Electrolytic Capacitor, 390 µF, 400 V

Electrolytic Capacitor, 390 µF, 400 V, ± 20%, Quick Connect, Snap-In, 8000 hours@ 105°CProduct InformationCapacitance: 390µFVoltage Rating: 400VVoltage(DC): 400VVoltage(AC): -Capacitance Tolerance: ± 20%Capacitor Terminals: Quick Connect, Snap-InLifetime @ Temperature: 8000 hours @ 105°CPolarity: PolarDiameter: 35mmProduct Range: ALA8DProduct Diameter: 35mmProduct Height: 35mmLead Spacing: 10mmESR: 0.394ohmOperating Temperature Min: -40°COperating Temperature Max: 105°CProduct Length: -Product Width: -Qualification: AEC-Q200Product OverviewThe KEMET ALA Snap-In Capacitors are designed for automotive applications. Theycan withstand vibration up to 20 G in accordance with the demanding requirementsof the Automotive Electronics Council's AEC-Q200 qualification. The ALA8Dcapacitance values cover a range from 200 to 620 µF and a voltage range of 400to 500 V.Designed for automotive usagesVibration proofAEC-Q200Long life, up to 8,000 hours at +105°C (Vr Ir applied)High ripple currentExcellent surge voltage capabilityPET sleeve recognized to UL QMTR2, UL No. E358957Optimized designs available upon request
