Kemet (ALC10C103EC063) Electrolytic Capacitor, Long Life, 10000 µF, 63 V

Electrolytic Capacitor, Long Life, 10000 µF, 63 V, ± 20%, Quick Connect, Snap-InProduct OverviewALC10 snap-in aluminium electrolytic capacitors covers a wide range of casesizes and voltage ratings. The ALC10 is designed for high voltage, it is up to600VDC, has high ripple current applications and features surge voltagecapability and very long-life performance. ALC10 capacitors are ideally suitedfor industrial and commercial applications demanding high reliability and longlife expectancy. Typical applications include frequency converters,uninterruptible power supply (UPS) systems and switch mode power supplies.(SMPS).Compact sizeLong life up to 18000 hours at +85°C (VR, IR applied)High ripple currentHigh voltageExcellent surge voltage capabilityComplies to IEC 60384-4 long life grade 40/85/56Product InformationCapacitance: 10000µFVoltage Rating: 63VVoltage(DC): 63VVoltage(AC): -Capacitance Tolerance: ± 20%Capacitor Terminals: Quick Connect, Snap-InPolarity: PolarLifetime @ Temperature: 18000 hours @ 85°CSeries Name: ALC10Diameter: 40mmProduct Diameter: 40mmProduct Range: ALC10Lead Spacing: 22.5mmESR: 0.08ohmProduct Height: 35mmOperating Temperature Min: -40°CLeakage Current: 3.784mAOperating Temperature Max: 85°CProduct Length: -Product Width: -Qualification: -Automotive Qualification Standard: -
