Kemet (ALS70A203KF100) Electrolytic Capacitor, Long Life, 20000 µF

Electrolytic Capacitor, Long Life, 20000 µF, 100 V, ± 20%, Screw, 20000 hours @85°CProduct InformationCapacitance: 20000µFVoltage Rating: 100VVoltage(DC): 100VVoltage(AC): -Capacitor Terminals: ScrewCapacitance Tolerance: ± 20%Lifetime @ Temperature: 20000 hours @ 85°CPolarity: PolarSeries Name: ALS70Diameter: 51mmLead Spacing: 22.2mmProduct Diameter: 51mmOperating Temperature Min: -40°COperating Temperature Max: 85°CHeight: 105mmESR: 0.022ohmProduct Height: 105mmProduct Length: -Product Width: -Qualification: -Product Range: ALS70Automotive Qualification Standard: -Product OverviewThe ALS70/71 high CV series of the screw terminal capacitors offer tremendousperformance and reliability in a wide range of case sizes and voltage ratings,featuring high ripple currents and long life performance. Volumetric efficiencyensures the maximum capacitance capability in a smaller size. They are ideallysuited for industrial and commercial applications, demanding high reliabilityand long life expectancy such as frequency converters, uninterruptible powersupply (UPS) systems and switch mode power supplies (SMPS).Long life, up to 20,000 hours at +85°C (Vr, Ir applied)High ripple currentExcellent surge voltage capabilityPET sleeve (recognized to UL: QMTR2 (UL No. E358957))Maximum capacitance capability in a smaller sizeOperational Life: 18000 Hrs
