Kemet (MPLCV1054L220) Power Inductor (SMD), 22 µH, 5.5 A, Shielded

Power Inductor (SMD), 22 µH, 5.5 A, Shielded, 7 A, MPLCV, 11.5mm x 10mm x 5.4mmProduct InformationInductance: 22µHRMS Current (Irms): 5.5AInductor Construction: ShieldedSaturation Current (Isat): 7AProduct Range: MPLCVPower Inductor Case: 11.5mm x 10mm x 5.4mmDC Resistance Max: 0.047ohmInductance Tolerance: ± 20%Product OverviewThe KEMET MPLCV metal composite inductors are ideal for use in DC to DCswitching power supplies for automotive applications. The combination ofcomposite core material and round wire allows these inductors to be used inapplications with high switching frequencies where efficiency is of upmostimportance.Improved power supply efficiency with composite metal coreMetal cores reduce losses and improves power supply efficiency at light loadsUsed as part of a filter or for energy storageHigh permeability for higher inductance with lower DC resistanceLow losses at higher switching frequenciesHigher current power and saturation in smaller packagesHigher current power and saturation in smaller packagesOperating Temperature -55°C to +155°CAEC-Q200 qualified
