Kemet (PEH200YX460BQU2) Electrolytic Capacitor, Long Life, 6000 µF, 450 V

Electrolytic Capacitor, Long Life, 6000 µF, 450 V, -10%, +30%, Screw, 19000hours @ 85°CProduct OverviewThe PEH200 series screw terminal Aluminium Electrolytic Capacitor has apolarized all-welded design, extended cathode construction, safety vent andplastic insulation. The sealing system is designed for electrolyte leakage-freeoperation and a very low gas-diffusion rate of electrolyte. Mechanical contactbetween the winding and aluminium case allows excellent heat transfer from thewinding hotspot to the ambient, which means cooler operation and very highcurrent ratings. Typical applications for KEMET's PEH200 capacitor includeuninterruptible power supplies (UPS), ground power units (GPU), weldingequipment and drives where high current ratings and compact size are important.High CVLong life up to 29000 hours at 85°C (VR, IR applied)Low ESR and ESLCompact size25 to 500VDC Rated voltage range100 to 330000µF CapacitanceOptimized designs availableProduct InformationCapacitance: 6000µFVoltage Rating: 450VVoltage(DC): 450VVoltage(AC): -Capacitance Tolerance: -10%, +30%Capacitor Terminals: ScrewPolarity: PolarLifetime @ Temperature: 19000 hours @ 85°CSeries Name: PEH200Diameter: 76.6mmProduct Diameter: 76.6mmProduct Range: PEH200Lead Spacing: 32mmESR: 0.012ohmProduct Height: 220mmOperating Temperature Min: -40°COperating Temperature Max: 85°CProduct Length: -Product Width: -Qualification: -Automotive Qualification Standard: -
