Kemet (PEH532YCB3120M2) Electrolytic Capacitor, Snap-in, 120 µF, 450 V

Electrolytic Capacitor, Snap-in, 120 µF, 450 V, ± 20%, Quick Connect, Snap-In,1500 hours @ 105°CProduct InformationCapacitance: 120µFVoltage Rating: 450VVoltage(DC): 450VVoltage(AC): -Capacitance Tolerance: ± 20%Capacitor Terminals: Quick Connect, Snap-InLifetime @ Temperature: 1500 hours @ 105°CPolarity: PolarDiameter: 31mmProduct Range: PEH532Product Diameter: 31mmProduct Height: 27mmLead Spacing: 10mmESR: 0.77ohmOperating Temperature Min: -40°COperating Temperature Max: 105°CProduct Length: -Product Width: -Qualification: -Automotive Qualification Standard: -Product OverviewThe PEH532 series snap-in long life Aluminium Electrolytic Capacitor designed tooffer high ripple current capability and low mounting cost. Low ESR is theresult of a very low resistive paper/electrolyte system. Low ESR, together withthe TDC thermal concept, gives the PEH532 a high ripple current capability.Typical applications for KEMET's PEH532 capacitor include switch mode powersupplies (SMPS), drives, welding equipment, uninterruptible power supplies (UPS)and other power electronic applications where high current ratings and compactsize are important.1,500 hours at 105°C (VR, IR applied)PCB mountingLow ESR and ESL35 to 450VDC Rated voltage range68 to 27000µF Capacitance
