Kemet (R46KR422000M2K) Safety Capacitor, Metallized PP

Safety Capacitor, Metallized PP, Radial Box - 2 Pin, 2.2 µF, ± 10%, X2, ThroughHoleProduct InformationDielectric Type: Metallized PPCapacitance: 2.2µFSuppression Class: X2Capacitor Case / Package: Radial Box - 2 PinVoltage Rating Y: -Capacitor Mounting: Through HoleCapacitance Tolerance: ± 10%Voltage Rating X: 275VACdv/dt Rating: 150V/µsHumidity Rating: GRADE II (Test Condition A)Capacitor Terminals: Radial LeadedLead Spacing: 27.5mmOperating Temperature Min: -40°COperating Temperature Max: 110°CProduct Range: R46 SeriesSeries Name: R46Qualification: -Product OverviewThe R46 Series is constructed of metallized polypropylene film encapsulated withself-extinguishing resin in a box of material meeting the requirements of UL 94V-0. For worldwide use in electromagnetic interference (EMI) suppression inacross-the-line applications requiring X2 safety classification. Intended foruse in situations where capacitor failure would not result in exposure toelectric shock. Not for use in "series with mains" type applications.Capacitance value ranges from 0.01µF to 10µFRated voltage is 275VACLead spacing varies from 10mm to 37.5mm±10% and ±20% toleranceOperating temperature range -40?C to +110?C100% screening factory test at 2,200VDC/1,500VACSelf healing propertiesENEC, UL, cUL, CQC approval standardsClimatic category 40/110/ 56, IEC 60068-1
