SPECIFICATIONS-(Batteries two years old need replacement)
Brand Kstar
Series Online UPS
Model KS-UA200
Phase Single Phase with Ground
Capacity 2000VA / 1200W
Input
Nominal Voltage 220/230/240 Vac
Frequency Range 50/60 Hz (1 ± 10%)
Output
Output Voltage 81-145V AC / 162-290 V AC
Operation
Transfer Time Typical 2-6 ms, 10ms max.
Waveform (Battery Mode) Approximated Sinewave (nominal voltage ±10%)
Battery
Batteries Included 2x 12V 9Ah Lead Acid
Typical Recharge Time 6-8 Hours Recover to 90% Capacity
Indicators
LED Array AC Mode, Battery Mode, Load Level, Battery Level
Alarms
Battery Mode Sounding every 10 seconds
Battery Low Sounding every second
Overload Sounding every 0.5 second
Battery Replacement Sounding every 2 seconds
Fault Continuously sounding
General
Colour Black
Humidity 0-95 % RH @ 0- 40°C (Non-Condensing)
Noise Level Less than 40dB @ 1 Meter
Dimensions 380 x 158 x 198mm (D x W x H)
Weight 11.5kg
Interface USB Type-B to Type-A
Operating System Support Windows 2000 32-bit / XP 32-bit / Vista 32-bit, 64-bit
Windows 7 / 8 or Later, 32-bit or 64-bit
Windows Server 2003 / 2008
Linux x86-64
UNIX
macOS
