L9110S H Bridge Stepper Motor Dual DC Driver Controller Module

L9110S H Bridge Stepper Motor Dual DC Driver Controller Module

New 28 available
Indicative market price: R50.92
R46.29
Shipping
R65.00 Standard shipping applies to orders under R100.00, in most areas in South Africa. R35.00 Standard shipping applies to orders over R100.00. Some areas may attract a surcharge surcharge. This will be calculated at checkout if applicable.
Check my rate
The seller has indicated that they will usually have this item ready to ship within 2 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery
Main centres:  1-3 business days
Regional areas: 3-4 business days
Remote areas: 3-5 business days
Seller
Buyer protection
Get it now, pay later

Product details

Condition
New
Location
South Africa
Product code
515
Bob Shop ID
613701312
There are two L9110S motor controller chips onboard
This module can simultaneously drive two DC motors or a 4-wire 2-phase stepper motor


Features

  • Work under low static current
  • Power supply voltage: DC 2.5V - 12V
  • Each channel has 800mA continuous current output
  • Low saturation pressure drop
  • TTL / CMOS output level compatible, can be connected directly to the CPU
  • Output built-in clamping diode, apply to the perceptual load
  • Control and drive integrate in IC
  • Pin high pressure protection function
  • Working temperature: 0°C - 80°C
  • Size: 29 x 21mm(L x W)


What's in the box?

1x L9110S stepper motor driver

Resources

Robot control with Python

Circuit diagram



Note: Stock is currently available in South Africa for national shipping!
