Camera
- Processor: GM8135S: SiP 512Mb DDR, ARM CPU core - 32-bit RISC, up to 600MHz
- Image sensor: 1MP 1/3 inch SC1135 low illumination CMOS sensor
- Lens: 1/2.5 Fisheye lensf=1.44mm
- Viewing angle: 360 degree
- Video Resolution: 960x960
- FPS: 25fps
- Image compression: JPEG
- Video Format: H.264 MP4
- Video coding: H.264
- Audio coding: ADPCM, support two way voice intercom
- Min LUX: 0.1Lux/F2.0
- Supported protocol: TCP/UDP, IP, HTTP, SMTP, DHCP, UPNP, NTP, ONVIF2.0
- Online visitor: support 10 visitor at the same time
- Alarm Notification: FTP Snapshot Upload, Event record to Micro SD Card
- Auto IR cut filter
- Power supply and consumption: DC5V, 1.6A
- Working condition: -10 to +50 Degrees Celsius
- Working humidity 10%-95% no condensation
Dimensions
- Main Product Dimensions: 130x 75x 75mm (L x W x D)
- Main Product Weight: 139g
Package Contents
- IP Camera
- E27 Base
- Screws
- User Manual
What's in the box
IP Camera
E27 Base
Screws
User Manual
