FEATURES

1× HDMI signal input and 4× HDMI signal output
Supports up to 3840×2160 @60Hz resolution, downwards compatible
Variety of splicing modes, such as 1×1/1×2/1×3/1×4/2×1/3×1/4×1/2×2
Dip switch splicing mode and RS232 control instruction to set splicing mode
3.5mm Left/Right channel audio output
180° Rotation of HDMI l/2 display image in 2x1/2x2 mode (when the upper displays are installed upside down)
Firmware upgrade via micro USB port
Lightning, Surge and ESD Protection

SPECIFICATIONS

Video Signal
HDMI Input: 1× HDMI
HDMI Output: 4× HDMI
Compatibility: HDMI 2.0, HDCP 1.4 / HDCP 2.0

Resolutions:
Input Resolution: up to 3840×2160 @60/50/30/25/24Hz, also supports 1080p @60/50/30/25/24Hz
Output Resolution: up to 3840×2160 @60Hz

Audio Output
3.5mm Left/Right Channel Audio Output (LPCM 2.0)
HDMI Output Audio: Supports Dolby Digital 5.1CH / DTS 5.1CH / LPCM 2.0

Display Wall / Splice Modes
Supported Display Wall / Splice Modes: 1×1, 1×2, 1×3, 1×4, 2×1, 3×1, 4×1, 2×2
Splicing Mode Configurable via DIP Switches or via RS232 Commands

Other Features
180° Rotation of HDMI Display Image in 2×1 or 2×2 Mode (For When Upper Displays Are Installed Upside-Down)
Firmware Upgrade via Micro-USB Port
Built-In Lightning, Surge and ESD Protection

Power and Environment
Power Supply: DC 12V 2A
Power Consumption: <9W
Operating Temperature Range: 20~60°C
Storage Temperature Range: 30~70°C
Humidity: 090% RH (Non-Condensing)

Physical Properties
Housing: Metal (Black)
Weight: 514g
Dimensions (L × W × H): 148.5 × 103 × 25mm
