"Key Specifications
Processor: Intel Core i7-13620H, 10C (6P + 4E) / 16T, P-core 2.4 / 4.9GHz, E-core 1.8 / 3.6GHz, 24MB
Memory: 16GB SO-DIMM DDR5-5200
Storage: 512GB SSD M.2 2242 PCIe 4.0x4 NVMe
Display: 16"" WQXGA (2560x1600) IPS 350nits Anti-glare, 100% sRGB, 165Hz, G-SYNC
Graphics: NVIDIA GeForce RTX 4050 6GB GDDR6, Boost Clock 2370MHz, TGP 95W
Operating System: Windows 11 Home Single Language, English
PERFORMANCE
Processor
Intel Core i7-13620H, 10C (6P + 4E) / 16T, P-core 2.4 / 4.9GHz, E-core 1.8 / 3.6GHz, 24MB
Graphics
NVIDIA GeForce RTX 4050 6GB GDDR6, Boost Clock 2370MHz, TGP 95W
Chipset
Intel SoC Platform
Memory
2x 8GB SO-DIMM DDR5-5200
Memory Slots
Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory
Up to 16GB DDR5-5200 offering
Storage
512GB SSD M.2 2242 PCIe 4.0x4 NVMe
Storage Support
Up to two drives, 2x M.2 SSD
M.2 2242 SSD up to 1TB
Storage Slot
Two M.2 slots
One M.2 2242 PCIe 4.0 x4 slot
One M.2 2280 PCIe 4.0 x4 slot
Card Reader
None
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek ALC3287 codec
Speakers
Stereo speakers, 2W x2, optimized with Nahimic Gaming
Audio
Camera
FHD 1080p with E-shutter
Microphone
2x, Array
Battery
Integrated 80Wh
Power Adapter
170W Slim Tip (3-pin)
Special Features
AI Chip: LA1
DESIGN
Display
16"" WUXGA (1920x1200) IPS 350nits Anti-glare, 45% NTSC, 144Hz, G-SYNC
Touchscreen
None
Color Calibration
None
Keyboard
4-Zone RGB Backlit, English
Case Color
Storm Grey
Surface Treatment
Painting
Case Material
PC-ABS (Top), PC-ABS (Bottom)
Dimensions (WxDxH)
359.6 x 277.6 x 21-25.9 mm (14.16 x 10.93 x 0.83-1.02 inches)
Weight
Starting at 2.6 kg (5.73 lbs)
SOFTWARE
Operating System
Windows 11 Home Single Language, English
CONNECTIVITY
Ethernet
100/1000M (RJ-45)
WLAN + Bluetooth
Wi-Fi 6, 11ax 2x2 + BT5.1
Standard Ports
1x Ethernet (RJ-45)
1x HDMI 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Power connector
1x USB 3.2 Gen 1
1x USB-C 3.2 Gen 2 (support data transfer, Power
Delivery 140W and DisplayPort 1.4)
2x USB 3.2 Gen 2
SECURITY & PRIVACY
Security Chip
Firmware TPM 2.0 Enabled
Fingerprint Reader
None
Other Security
E-shutter
SERVICE
CERTIFICATIONS
Green Certifications
ErP Lot 6
ErP Lot 26
RoHS compliant"
Screen size: 16" WUXGA (1920x1200) Display
Processor: Intel Core i7-1260P processor
Storage: 512GB PCIe NVMe M.2 SSD
Memory: 16GB DDR4 system memory
Graphics: NVIDIA GeForce RTX 4050 6GB GDDR6
Operating System: Windows 11 Pro
PERFORMANCE
Processor - Intel Core i7-13620H, 10C (6P + 4E) / 16T, P-core 2.4 / 4.9GHz, E-core 1.8 / 3.6GHz, 24MB
Graphics - NVIDIA GeForce RTX 4050 6GB GDDR6, Boost Clock 2370MHz, TGP 95W
Chipset - Intel SoC Platform
Memory - 2x 8GB SO-DIMM DDR5-5200
Memory Slots - Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory - Up to 16GB DDR5-5200 offering
Storage - 512GB SSD M.2 2242 PCIe 4.0x4 NVMe
Card Reader - None
Optical - None
Audio Chip - High Definition (HD) Audio, Realtek ALC3287 codec
Speakers - Stereo speakers, 2W x2, optimized with Nahimic Gaming Audio
Camera - FHD 1080p with E-shutter
Microphone - 2x, Array
Battery - Integrated 80Wh
Power Adapter - 170W Slim Tip (3-pin)
Special Features - AI Chip: LA1
DESIGN
Display - 16" WUXGA (1920x1200) IPS 350nits Anti-glare, 45% NTSC, 144Hz, G-SYNC
Touchscreen - None
Color Calibration - None
Keyboard - 4-Zone RGB Backlit, English
Case Color - Storm Grey
Surface Treatment - Painting
Case Material - PC-ABS (Top), PC-ABS (Bottom)
Dimensions (WxDxH) - 359.6 x 277.6 x 21-25.9 mm (14.16 x 10.93 x 0.83-1.02 inches)
Weight - Starting at 2.6 kg (5.73 lbs)
SOFTWARE
Operating System - Windows 11 Home Single Language, English
CONNECTIVITY
Ethernet - 100/1000M (RJ-45)
WLAN + Bluetooth - Wi-Fi 6, 11ax 2x2 + BT5.1
Standard Ports:
1x Ethernet (RJ-45)
1x HDMI 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Power connector
1x USB 3.2 Gen 1
1x USB-C 3.2 Gen 2 (support data transfer, Power Delivery 140W and DisplayPort 1.4)
2x USB 3.2 Gen 2
Security Chip - Firmware TPM 2.0 Enabled
Fingerprint Reader - None
Other Security - E-shutter
What's in the box
- 1 x Notebook
- 1 x AC Adapter
