LinkQnet - 500M Roll Cat5E Solid Network Cable - Green - LinkQnet - 500M Roll Cat5E Solid Network...

LinkQnet CAT5e UTP Solid Network Cable - Green (Sold per Meter or 500m Drum)

The UTP Cat5e Network Cable is engineered for reliable, high-performance structured cabling in modern LAN environments. Built with solid 24 AWG copper conductors and precision-twisted pairs, it delivers stable Gigabit Ethernet connectivity with reduced crosstalk and excellent signal integrity. Designed to meet international cabling standards, this cable is ideal for office networks, patch panels, switches, IP devices, and general data installations, ensuring dependable performance for both commercial and residential networking projects.

FEATURES

Category 5e Performance - Supports high-speed Ethernet networking for reliable LAN connectivity
24AWG Solid Copper Conductors - Ensures stable signal transmission and consistent network performance
Four Twisted Pair Design - Minimises crosstalk and interference for cleaner data signals
Standards Compliant - Meets ISO 11801, TIA/EIA 568-C.2 and EN50173 structured cabling standards
Durable PVC Jacket - Provides protection and flexibility for structured cabling installations
Wide Operating Temperature Range - Reliable performance from -20°C to +70°C

SPECIFICATIONS

CONDUCTOR
24AWG Solid Bare Copper (0.511mm)

INSULATION
Polyethylene

PAIR COLOURS
Blue / White-Blue (0.95mm)
Green / White-Green (0.95mm)
Orange / White-Orange (0.91mm)
Brown / White-Brown (0.91mm)

SHEATH
PVC
Nominal OD: 5.2mm

FIRE SAFETY RATING
IEC 60332-1

TEMPERATURE RANGE
Installation: 0~50°C
Operational: -20~70°C

ELECTRICAL CHARACTERISTICS (AT 20°C)
DC Resistance: 93.8 Ohms/km Max.
Resistance Unbalance: 2% Max.
Mutual Capacitance: 56 nF/km Max.
Capacitance Unbalance: 1000 pF/km Max.
Skew: 450 ns/km Max.
Velocity of Propagation: 68% (0.68 × 3 × 10 m/s)
Characteristic Impedance: 100 Ohms ±15% (1~100MHz)
