LM2596 DC Buck Voltage Regulator
Check my rate
| Main centres: | 1-3 business days |
| Regional areas: | 3-4 business days |
| Remote areas: | 3-5 business days |
Product details
Specifications:
Input voltage: 5-36V
Output voltage: 1.25-32V continuously adjustable
Output current: adjustable 5A MAX (recommended below 4.5A)
Output power: maximum 75W (recommended below 50W in the pressure difference, please reduce the power)
Operating temperature: -40 degrees to +85 degrees
Working frequency: 180KHz Conversion efficiency: up to 96% Short circuit protection
Overheat protection (over temperature automatic shutdown output)
Reverse link protection: No (add diode if necessary)
Applications:
Over-current protection step-down module.
As a variety of voltage battery charger for solar panels, wind turbines.
A high-power LED constant current driver module.
Precautions:
If the output power is greater than 3A 35W, please strengthen the heat.
If your load is a USB device, make sure the output voltage is 5V
