LM2596S DC-DC STEP DOWN ADJUSTABLE POWER SUPPLY MODULE
Product information
This Module uses the well-known LM2596S voltage switching regulator. Just connect your DC voltage to IN+ and IN-, adjust the potentiometer to meet your output voltage requirements and that is it.
Note! IN- and OUT- are connected together on the board, so they are all GND.
Specifications
Input voltage: 4V - 35V
Output voltage: 1.25 - 30V (adj.)
Output current: rated current 2A, maximum 3A (add a heatsink if the output power is greater than 15W)
Conversion efficiency: Up to 92% (the higher the output voltage, the higher the efficiency)
Switching frequency: 160 KHz
Minimum dropdown voltage: 2V
Rectifier: Non-Synchronous Rectification
Module Properties: Non-isolated step-down module
Short circuit protection: current limiting
Operating temperature: Industrial grade (-40 to +85 ) (output power 10W or less)
Full load temperature rise: 40
Load regulation: ± 0.5%
Voltage regulation: ± 0.5%
Dynamic response speed: 5% 200uS
Dimensions: 48 x 23 x 12mm
Package Includes
1 x LM2596S Adjustable Step Down Module
