LM35DZ Precision Centigrade Temperature Sensor

The LM35-series devices are precision integrated-circuit temperature sensors, with an output voltage linearly proportional to the Centigrade temperature. The LM35 device has an advantage over linear temperature sensors calibrated in Kelvin, as the user is not required to subtract a large constant voltage from the output to obtain convenient Centigrade scaling. The LM35 device does not require any external calibration or trimming to provide typical accuracies of ± ¼ °C at room temperature and ± ¾ °C over a full 55°C to 150°C temperature range. Lower cost is assured by trimming and calibration at the wafer level. The low output impedance, linear output, and precise inherent calibration of the LM35 device makes interfacing to readout or control circuitry especially easy. The device is used with single power supplies, or with plus and minus supplies. As the LM35 device draws only 60 A from the supply, it has very low self-heating of less than 0.1°C in still air. The LM35 device is rated to operate over a 55°C to 150°C temperature range

Features

Calibrated Directly in Celsius (Centigrade)
Linear 10-mV/°C Scale Factor
0.5°C Ensured Accuracy (at 25°C)
Rated for Full 55°C to 150°C Range
Suitable for Remote Applications
Low-Cost Due to Wafer-Level Trimming
Operates From 4 V to 30 V
Less Than 60-A Current Drain
Low Self-Heating, 0.08°C in Still Air
Non-Linearity Only ±¼°C Typical
Low-Impedance Output, 0.1 for 1-mA Load

Applications

Power Supplies
Battery Management
HVAC
Appliances

What's in the box?

1 x LM35DZ temperature sensor
