Solar Input
Maximum DC Input Power: 8000W
Nominal DC Input Voltage: 360VDC
DC Input Voltage Range: 100VDC-550VDC
MPPT Voltage Range: 120VDC-500VDC
Start Voltage: 140VDC
Number of MPP Trackers: 2
Maximum DC Input Current: 12.5A / 12.5A
Battery Input / Output
Compatible Battery Type: Lithium-ion / Lead-Acid
Nominal Battery Voltage: 48VDC
Battery Voltage Range: 40VDC 60VDC
Maximum Charge / Discharge Current: 80A / 80A
Maximum Charge / Discharge Power: 5000W / 5000W
Charging Curve: 3 StagesData-sheet-5Kw-Luxpower-LXP5K
AC Input / Output
Nominal AC Output Power: 5000W
Nominal AC Output Current: 25A
Nominal AC Voltage: 230VAC (180VAC-270VAC)
Nominal AC Frequency: 50Hz / 60Hz (45Hz-55Hz / 55Hz-65Hz)
Power Factor: >0.99 @ Rated Power 0.8 Lagging 0.8 Leading Adjustable
Environment Limit
Ingress Protection: IP65
Relative Humidity: 0% to 100%
Operating Temperature Range: -25C to +60C
Operating Altitude: <2000m
Communication: RS485 / WIFI / CAN
