Magnetic plastic case type Nb8 series circuit breaker

1.1 Function

protection of circuits against short-circuit currents,
switch, isolation.
NB8 -63M circuit-breakers are used in domestic installation,
as well as in commercial and industry electrical
distribution systems.

1.2 Selection
Technical data of the network at the point considered:
short-circuit current at the circuit-breaker installation point,
which must always be less than the breaking capacity of
this device, network normal voltage.
C curve (6.4In-9.6In)
protection for resistive and inductive loads with low inrush
current.
D curve(9.6-14.4In)
protection for circuits which supply loads with high inrush
current at the circuit closing
(LV/LV transformers, breakdown lamps).
