Male Active Displayport to VGA Female Cable (ATI Eyefinity Tested, works on all Displayport devices)

This cable has been tested with ATI EYEFinity and allows up to 6 screens to be configured on ATI Graphics cards having the Eyefinity capability to display one image across multiple displays.

DisplayPort is a new digital video and audio connection standard designed by the Video Electronics Standards Association (VESA). It is a royalty-free technology designed primarily for the computer industry but also compatible for home theater application. The format supports both digital video and audio using a single cable.

Here's a simple solution for connecting your DisplayPort equipment devices using VGA cables to your existing VGA Display. This simple adapter is all you need to convert from one format to the other.

- Max Supported Resolution - 1920x1080p, 1920x1200
- 5.4 Gbps Bandwidth input over 2 lanes Integrated triple 10-bit, 162MHz Video DAC for Analog VGA signal Output

DisplayPort was primarily designed as a replacement for VGA, DVI and LVDS which are common interfaces used in the computer / IT industries, while HDMI was developed by the Consumer Electronics Industry specifically for Home Theater applications. Toward this end, DisplayPort has certain enhanced features such as direct drive monitor design and single cable multi-function monitor connectivity. Some advantages of HDMI are the ability to support xvYCC color, Dolby TrueHD and CEC (Consumer Electronics Control) signals.

Though both share powerfull A/V features, DisplayPort was designed to complement HDMI, not to replace it.
