MAX7219 Dot Matrix MCU LED Display Control Module Kit ( Green)

MAX7219 Dot Matrix MCU LED Display Control Module Kit ( Green)

13 available / new
Indicative market price: R63.67
R57.88
Shipping
R65.00 Standard shipping applies to orders under R100.00, in most areas in South Africa. R35.00 Standard shipping applies to orders over R100.00. Some areas may attract a surcharge surcharge. This will be calculated at checkout if applicable.
Check my rate
The seller has indicated that they will usually have this item ready to ship within 2 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery
Main centres:  1-3 business days
Regional areas: 3-4 business days
Remote areas: 3-5 business days
Seller
Buyer protection
Get it now, pay later

Product details

Condition
New
Location
South Africa
Product code
2525
Bob Shop ID
613701518
Looking for easy to control LED matrix? This 4 in 1 Dot Matrix Display module should be suitable for you. The whole module comes in four 8x8 RED common cathode dot matrix that equiped with MAX7219 IC each. Great to display running text and picture. It can be cascaded to bigger dot Matrix display, but do make sure the current of 5V is sufficient to support it.

Specifications

A single module can drive a 8x8 dot matrix common cathode
Working voltage: 5V
Module size: 12.8 x 3.2 x 1.3 cm (L*W*H)
With 64 fixing screw holes, hole diameter: 3mm
Module with input and output interfaces, support for cascading multiple modules

What's in the box?

1 x MAX7219 Dot Matrix Module
1 x 5pin jumper Cable

Resources

Wiring

1. The left side of the module is the input port, and the right is the output port.
2. Control of a single module, the input port only need to receive CPU.
3. The more a module cascade and input end of the first module is connected with the CPU and input end of the input end of the output end is connected to the second module, output terminal of the second module connected with the three modules, and so on.
For example: 51 SCM
VCC5V
GNDGND
DINP2.2
CS P2.1
CLKP2.0




MAX7219 Dot Matrix Module 4-in-1 Display For Arduino


MAX7219 Dot Matrix Module 4-in-1 Display For Arduino



https://max7219.readthedocs.io/en/0.2.3/
Clock example
Python Library
Note: Stock is currently available in South Africa for national shipping!
Add to cart
