Mean Well (DDR-30G-12) Isolated DIN Rail Mount DC/DC Converter, 12 V, 2.5 A

Isolated DIN Rail Mount DC/DC Converter, Railway, 4:1, 30 W, 1 Output, 12 V, 2.5AProduct InformationPower Supply Approvals: RailwayInput Ratio: 4:1Output Power Max: 30WNo. of Outputs: 1 OutputOutput Voltage - Output 1: 12VOutput Current - Output 1: 2.5AIsolation Voltage: 4kVDC / DC Converter Output Type: Fixed, AdjustableInput Voltage DC Nom: 24VWidth: 35mmHeight: 90mmDepth: 54.5mmInput Voltage DC Min: 9VInput Voltage DC Max: 36VProduct Range: DDR-30 SeriesProduct OverviewDDR-30G-12 is a DDR-30 series 30W DIN rail type DC-DC converter with mainfeatures including easy installation, ultra slim width (35mm), 4:1 ultra wideinput voltage, 4KVdc I/O isolation, adjustable output voltage (±10%) and fullprotective functions. It can be used for industrial control, security control,communication system and other fields. Suitable applications are DC buck/boostregulator, increasing system insulation level and voltage drop compensationalong cable. It includes short circuit, overvoltage, overload protection, inputreverse polarity, input under voltage protection. Application includesindustrial control system, semi-conductor fabrication equipment, factoryautomation, electro-mechanical, wireless network, telecom or datacom system.Approved by UL/IEC 62368-1, AS/NZS 62368.1, design refer to UL508.Input voltage range from 9 to 36VDC, output DC voltage is 12VOutput rated current is 2.5A, output rated power is 30W, typical efficiency is86%No minimum load requiredCooling by air free convection3 years warrantyWorking temperature range from -40 to +85°CDimension is (W x H x D) 35 x 90 x 54.5mm
