Meanwell Power Supply RSP 500W - 48V - 10.5A

Meanwell Power Supply RSP 500W - 48V - 10.5A

Product Description

The RS-P-500 is a 500W single-output enclosed type AC/DC power supply. This series operates for 85~264VAC input voltage and offers the models with the DC output mostly demanded by the industry. Each model is cooled by the built-in fan with fan speed control, working for the temperature up to 70. Moreover, the RS-P-500 provides vast design flexibility by equipping various built-in functions such as remote ON-OFF control, remote sense, DC OK signal, etc.

Product Features

• Universal AC Input/Full Range
• Built-in active PFC function
• High efficiency up to 90.5%
• Forced air cooling by built-in DC fan (Note: 0.5)
• Built-in remote ON-OFF control/remote sense/DC OK signal
• Protections: Short circuit/overload/over voltage/over temperature

Product Specifications

• Brand: Meanwell
• DC Voltage: 48V
• Rated Current: 10.5A
• Current Range: 0 ~ 10.5A
• Rated Power: 504W
• Ripple & Noise (max): 150mVp-p
• Voltage ADJ. Range: 41 ~ 56V
• Voltage Tolerance: ±1.0%
• Line Regulation: ±0.2%
• Load Regulation: ±0.5%
• Setup, Rise Time: 1500ms, 80ms/230VAC; 3000ms, 80ms/115VAC at full load
• Hold Up Time (Type): 18ms/230VAC; 14ms/115VAC at full load

Product Resources

Data Sheet

Locally stocked. Available for immediate shipping.
