MECER 10KVA ME-10000-WPTU 10000VA/8000W Tower Type Online UPS Winner Pro 10K

BRAND: MECER

Mecer 10000VA On-Line Tower UPS (ME-10000-WPTU)
Phase Single phase with ground
Capacity: 10000 VA / 8000 W
Frequency Range: 46~54 Hz or 56~64 Hz
Battery Type: 12 V / 9 Ah (16 batteries )
Pure Sinewave
InputVoltage Range
Low Line Transfer 176 VAC ± 3% @ 100% load, 110 VAC ± 3% 50% load
Low Line Comeback 186 VAC ± 3% @ 100% load, 120 VAC ± 3% 50% load
High Line Transfer 300 VAC ± 3%
High Line Comeback 290 VAC ± 3%
Frequency Range 46~54 Hz or 56~64 Hz
Power Factor 0.99 @ 100% load
Output Output Voltage 208/220/230/240 VAC
Frequency Range (Batt. Mode 50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz
Current Crest Ratio 3:1
Harmonic Distortion 3 % THD (Linear Load), 5 % THD (non-linear load)
Transfer Time AC Mode to Batt. Mode Zero
Inverter to Bypass Zero
Typical Recharge Time 9 hours to recover to 90% capacity
Charging Current (max.) 1.0 A / 2.0 A (adjustable)
Charging Voltage 218.4 VDC ± 1%
Indicators LCD Panel UPS status, Load level, Battery level, Input/output Voltage, Discharge timer and Fault Conditions
Alarm Battery Mode Sounding every 4 seconds /Low Battery- Sounding every second/Overload
Sounding twice every second Fault
Continuously sounding
Physical Dimension, D x W x H (mm)442 x 190 x 688Net Weight (kgs) 6
Management Smart RS-232/USB Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8, Linux, Unix and Mac
Optional SNMP
Power management from SNMP manager and web browser

Batteries are still in good nick, would need to replace them in the next year or two, bigger battery packs can be added like 100amp etc
