Mecer 12V 720W Simulated Sinewave Inverter - Mecer

MODEL: IVR-1200LBKS

CAPACITY: 1200VA/ 720W

INPUT

- Voltage: 230 VAC

- Acceptable Voltage Range: 90-280 VAC

- Frequency: 50 Hz/60 Hz (Auto sensing)

OUTPUT

- AC Voltage Regulation (Batt. Mode): ± 10%

- Efficiency (Peak): 82%

- Transfer Time: 20 ms typical

- Waveform (Batt. Mode): Simulated sine wave

BATTERY & AC CHARGER

- Battery Voltage: 12 VDC

- Floating Charge Voltage: 13.7 VDC ±2%

- Low Battery Alarm Voltage: 10.2Vdc ±2%

- Shutdown Voltage: 9.9Vdc ±2%

- Overcharge Protection: 15.0Vdc ±2%

- Maximum Charge Current: 10 A or 20 A (Selectable)

SOLAR CHARGER (Optional) "Solar Charge controller not included,will request to purchase separately"

- Maximum PV Array Open Circuit Voltage: 40 VDC

- Operating Voltage Range: 15~18 VDC

- Maxmum Solar Charge Current: 50 A

PROTECTION

- Full Protection: Overload, short circuit and polarity reserve protection

PHYSICAL

- Dimension, D X W X H (mm): 300 x 360 x 88

- Net Weight (kgs): 4.6

OPERATING ENVIRONMENT

- Humidity: 0 to 90% Relative Humidity(Non-condensing)

- Operating Temperature:  0℃ to 40℃

- Storage Temperature:  -15℃ to 50℃

Warranty

- 1 Year Warranty

* Product specifications are subject to change without further notice
