Mecer 2400VA, 1440W, 24V DC-AC Inverter

Mecer 2400VA, 1440W, 24V DC-AC Inverter with LCD Display. No solar built-in (option not available).. Batteries not included. Includes: Battery cables, 1x cable with SA 3pin plug. Requires 2x 12V deep cycle batteries. Please take note of connection polarity (+Red, - Black). Output: 3-pin South African sockets at back of unit (SANS 164-1).
IVR-2400LBKS
Mecer 2400VA, 1440W, 24V DC-AC Inverter
Mecer 2400VA, 1440W, 24V DC-AC Inverter with LCD Display. No solar built-in (option not available).. Batteries not included. Includes: Battery cables, 1x cable with SA 3pin plug. Requires 2x 12V deep cycle batteries. Please take note of connection polarity (+Red, - Black). Output: 3-pin South African sockets at back of unit (SANS 164-1).
Features:
Simulated sinewave inverter
Wide input voltage range
12VDC or 24VDC available
Overload and short circuit protection
LCD display for comprehensive information
*Please take note of connection polarity (+Red , - Black). : Connect RED cable to (+) on battery and the (+) on the unit, and BLACK cable to (-) on battery and the (-) on the unit. Place cable lug directly onto the battery terminal first, follow up with the washer and then the lock washer, and then the nut. Do not put a washer between the battery terminal and cable. Connect the positive cable first. Follow instructions in manual.
FAQ:Does this product function like a ups?Yes, it does function similar to a UPS, without the constant beeping.Can I have everything connected to it and as soon as electricity goes then it'll power up from batteries and when electricity resumes it'll get charged automatically?Yes, you have 220V outlets, and you can leave everything plugged in. When power goes out, everything continues to work without interruption.
Specifications
Product Code
IVR-2400LBKS
MODEL
IVR-2400LBKS
CAPACITY
2400VA/ 1440W
INPUT
Voltage
230 VAC
Acceptable Voltage Range
90-280 VAC
Frequency
50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)
± 10%
Efficiency (Peak)
85%
Transfer Time
20 ms typical
Waveform (Batt. Mode)
Simulated sine wave
BATTERY & AC CHARGER
Battery Voltage
24 VDC
Floating Charge Voltage
27.4 VDC ±2%
Low Battery Alarm Voltage
20.4Vdc ±2%
Shutdown Voltage
19.8Vdc ±2%
Overcharge Protection
30.0Vdc ±2%
Maximum Charge Current
10 A or 20 A (Selectable)
PROTECTION
Full Protection
Overload, short circuit and polarity reserve protection
PHYSICAL
Dimension, D X W X H (mm)
300 x 360 x 88
Net Weight (kgs)
4.8
OPERATING ENVIRONMENT
