FEATURES

4G LTE Connectivity - Share internet access with up to 32× Wi-Fi devices and enjoy download speeds of up to 150Mbps
Plug-and-Play Setup - Simply insert a SIM card to create your wireless network with no configuration required
300Mbps Wi-Fi Speeds - Provides fast 2.4GHz wireless connectivity for smooth browsing, streaming and everyday use
Maximum Network Coverage - Four external antennas deliver stable connections and wider wireless coverage
Flexible Router Mode - LAN/WAN port supports wired broadband connection when a 4G network is unavailable

SPECIFICATIONS

WIRELESS
Network Type:
- FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700MHz)
- TDD-LTE: B38/B40 (2600/2300MHz)
- HSPA+/UMTS: B1/B5/B8 (2100/850/900MHz)

Wi-Fi Class: N300
Wi-Fi (2.4GHz): 300Mbps
Wireless Standards: IEEE 802.11b/g/n
Frequency: 2.4GHz

RECEPTION SENSITIVITY
11g 54M: -74.5dBm
11n HT20 MCS7: -73.5dBm
11n HT40 MCS7: -70.5dBm

TRANSMISSION POWER
<20dBm (2.4GHz)

WIRELESS SECURITY
WPA-PSK
WPA2-PSK

WIRELESS FUNCTIONS
Smart Connect
WPS
Wireless Schedule
Wireless Clients Statistics

SOFTWARE

OPERATION MODES
3G/4G Router
Wireless Router

CELLULAR MODE
4G Preferred
4G Only
3G Only

CELLULAR APN
Data Roaming
Network Search
Profile Create
APN Settings
ISP File Upgrade
PIN Management

WAN MODE
Dynamic IP
Static IP
PPPoE
PPTP
L2TP

DHCP
Server
DHCP Client List
Address Reservation

NAT FORWARDING
ALG
Virtual Server
Port Triggering
UPnP
DMZ

PROTOCOLS
IPv4
IPv6

DATA SETTINGS
Data Statistics
Data Limit

GUEST NETWORK
2.4GHz Guest Network

PARENTAL CONTROLS
Time Control
Website Filtering

DDNS
Mercusys DDNS
DynDNS
NO-IP

SMS
Inbox
New Message
Outbox
Drafts

SECURITY
IPv4 SPI Firewall
Access Control
Service Filtering
IP and MAC Binding
IPv6 Firewall

SYSTEM SETTINGS
Time Settings
LED Control
Diagnostics
Firmware Upgrade
Backup and Restore
Reboot
Administration
System Log
CWMP Settings

DEVICE MANAGEMENT
Mercusys App
Web GUI

TR-069
Supported

HARDWARE
Dimensions (W × D × H): 219 × 140 × 32mm
Interfaces:
- 1× 10/100Mbps LAN/WAN Port
- 3× 10/100Mbps LAN Ports
- 1× Nano SIM Card Slot
Antenna:
- 2× External 4G LTE Antennas
- 2× External Wi-Fi Antennas
Button: WPS / Reset Button
External Power Supply: 9V 0.85A

LED
Power
Internet
LAN
Signal (3×)

LTE STANDARD
CAT4
150Mbps Download / 50Mbps Upload

ENVIRONMENT
Operating Temperature: 0~40°C
Storage Temperature: -40~60°C
Operating Humidity: 10~90% RH (Non-Condensing)
Storage Humidity: 5~90% RH (Non-Condensing)
