FEATURES

Full Gigabit Ports - 5× 10/100/1000Mbps RJ45 ports
Two Cables in One - With four PoE+ ports, transfers data and power on one single cable
High Power PoE+ - Support PoE Power up to 30W for each PoE port and 65W for all PoE ports
Long-Range up to 250m - Increases PoE transmission distance up to 250m with Extend Mode (Speed decreasing to 10Mbps)
Isolation Mode - One click to divide traffic for specific ports for stability and security
Compliant with Powered Devices - Works with IEEE 802.3af/at compliant PDs
Durable Metal Casing - Allows for efficient heat dissipation and long network life
Plug-and-Play - Simple to use and saves time and effort

SPECIFICATIONS

DIMENSIONS (W × D × H)
171 × 98 × 27mm

POE PORTS
7× PoE+ Ports (Ports 1~7)
Standard: IEEE 802.3af/at Powered Devices
PoE Power Budget: 65W

INTERFACES
8× RJ45 Gigabit Ethernet Ports

EXTERNAL POWER SUPPLY
External Power Adapter (Output: 53.5V 1.31A)

INSTALLATION
Desktop
Wall Mount

STANDARDS AND PROTOCOLS
IEEE 802.3x Flow Control

DATA RATES
10/100/1000Mbps at Half-Duplex
20/200/2000Mbps at Full-Duplex

JUMBO FRAME
15KB

MAC ADDRESS TABLE
8K

MAX POWER CONSUMPTION
5.07W (220V 50Hz, No PD Connected)
77.33W (220V 50Hz, With 65W PD Connected)

MAX HEAT DISSIPATION
17.238 BTU/h (No PD Connected)
262.922 BTU/h (With 65W PD Connected)

ENVIRONMENT
Operating Temperature: 0~40°C
Storage Temperature: -40~70°C
Operating Humidity: 10~90% RH Non-Condensing
Storage Humidity: 5~95% RH Non-Condensing
