Description :

Ideal for mobile use due to low weight

Stable gear for uniform work piece feed

Convenient height adjustment with crank handle

Easy setting of common passage heights using stop points

Powerful universal motor for powerful lugging drive and even planing result

Restart protection: prevents unintentional start-up after power supply interruption

Precise thickness adjustment for quick and exact planing

Large feed and exit tables support the conveyance of long materials

Planing locking mechanism prevents unintentional adjustment of the chip removal setting

Specifications :

Dimensions: 579 x 857 x 574 mm / 1.9 x 2.9 x 1.9 ft
Thickness planing: 0 3 mm // 0 1/8
Thickness table: Cast aluminium / special steel aluminium
Thickness table L x W: 840 x 330 mm / 33 x 13
Passage height/width: 152 / 330 mm / 6 / 13
Feed rate: 7 m/min / 16 ft/min
Diameter of blade shaft: 47 mm / 1 7/8
Number of blades: 2
Revolutions of blade shaft: 9800 RPM
Rated input power: 1.8 kW
Weight: 35 kg / 77.2 lbs
