Microchip (MCP23008-E/SO) I/O Expander, 8bit, 1.7 MHz

Product OverviewThe MCP23008-E/SO is a 8bit I/O expander with high speed I2C interface in 18lead SOIC package. This I/O expander provides 8bit, general purpose parallel I/Oexpansion for I2C bus applications. The MCP23008 consists of multiple 8bitconfiguration registers for input, output and polarity selection. The systemmaster can enable I/Os as either inputs or outputs by writing I/O configurationbits. Data for each input or output is kept in corresponding input or outputregister. The polarity of input port register can be inverted with polarityinversion register. All registers can be read by system master.8bit remote bidirectional I/O portThree address pins to allow up to eight devices on busMaximum bus frequency is 1.7MHzInterrupt output pin can be configured as active high, active low or open drainConfigurable interrupt sourceExternal reset inputLow standby current of 1µA maximumSupply voltage range from 1.8V to 5.5VOperating temperature range -40°C to 125°CApplicationsCommunications & NetworkingProduct InformationChip Configuration: 8bitBus Frequency: 1.7MHzIC Interface Type: I2C, SerialSupply Voltage Min: 1.8VSupply Voltage Max: 5.5VInterface Case Style: SOICNo. of Pins: 18PinsNo. of I/O's: 8I/O'sProduct Range: -Automotive Qualification Standard: -MSL: -
